Liquid / HLQ-4V

- Features
-
- HLQ-4V produces single serve stick packaging and is designed for free-flowing liquids and pastes
- Ability to control the accuracy of the fill quantity
- PLC Control enables a simple and easy user-oriented interface via the LCD control panel.
- Photo-eye adjustment is handled via the touch screen LCD control panel.
- Film loss is reduced through the use of an automatic tensioning system (optional)
- Product contact areas are made of coated light metals and SUS316 for hygienic use.
- Certified waterproof class of IP54 – 64
- Downstream equipment available to pack, stack or carton the finished product
- Applications
-
- Video
-
- Specification
-
Model
HLQ-4V
Packing Line
2 - 10 Lines
Capacity
110 - 550 PPM (10 Lines)
Dimension(mm)
1,692(W) X 1,995(L) X 2,300(H)
Packing Size(mm)
30 - 100(W) X 20 - 180(L)
Filling Capacity
1 - 150g
Packing Type
4 Sides Embossing Sealing
Adjustment of Print
Photo-eye print registration & Servo Control
Power Consume
3 Phase, 220/380/440V X 50/60Hz (5 - 7Kw/h)
Electric Power
Motor 0.75Kw / Heater 800 - 1200W
Weight
about 1,500 - 2,300kg
